13. TECHNICAL CHARACTERISTICS 13. CARACTERÍSTICAS TÉCNICAS
13. CARACTÉRISTIQUES TECHNIQUES 13. TECHNISCHE DATEN
INPUT 1, 2 (LINE)
Sensitivity 0 / -6dBV Internal jumper adjust. 0dBV factory default
Input impedance >13k
Input connector RCA female
INPUT 3, 4, 5, 6 (MIC)
Sensitivity -20 / -50dBV External potentiometer adjust
Input impedance >24k electronically balanced
CMRR >55dB (20Hz ÷ 20kHz)
Input connector Terminal block (Symmetrical)
INPUT 3, 4, 5, 6 (LINE)
Sensitivity 0 / -6dBV Internal jumper adjust. 0dBV factory default
Input impedance >24k electronically balanced
CMRR >55dB (20Hz ÷ 20kHz)
Input connector Terminal block (Symmetrical)
ZONE OUTPUTS
Nominal output level 0dBV
Output impedance
300 electronically balanced
Output connector Terminal block (Symmetrical)
A/D & D/A
24bit / 48kHz
FREQUENCY RESPONSE
<10Hz ~ 20kHz (+0dB / -0.5dB)
OUTPUT NOISE FLOOR (FFT)
>110dB (from 20Hz to 20kHz)
THD + NOISE
< 0.0058% (1kHz, 1Vrms)
CROSSTALK
>90dB, 20Hz ÷ 20kHz
INPUT EQ
Type Baxandall 3 ways EQ
Gain -10dB ~ +10dB in 0.1dB steps
Frequency Low 200Hz Mid 1kHz High 6.3kHz
INPUT 3, 4, 5, 6 TALKOVER
Type Assignable to any output zone. 2 priority levels.
Modes Ducker / Pager (only input 6)
Threshold -80 / +12dBV
Depth 0 ~ 80dB
Attack time 5 ~ 2000ms
Hold Time 10 ~ 3000ms
Release time 50 ~ 3000ms
Chime (only input 6) ON / OFF. Variable volume. Two different melodies
INPUT 3, 4, 5, 6 NOISE GATE
Threshold -80 / +12dBV
Depth 0 ~ 80dB
Attack time 0.1 ~ 500ms
Hold Time 10 ~ 3000ms
Release time 10 ~ 1000ms
