2. INTRODUCTION
DAM614 DIGITAL AUDIO MIXER
The DAM614 is a digital audio mixer featuring 6 audio inputs and 4 outputs, DSP processing, RS-
232 connectivity and four remote control ports (0-10VDC).
Main features
 2 stereo line inputs, with RCA connectors
 4 balanced dual inputs (microphone/line), with Euroblock connectors, configurable as
independent inputs (mono) or per pair as a third and fourth stereo input
 4 balanced audio outputs, with Euroblock connectors: each output is configurable as a separate
zone output (mono) or as a linked output for a stereo zone (A&B/C&D)
 DSP with 24-bit quantization and 48kHz sampling frequency
 2x20 characters LCD Display on the front panel
 4 setup keys on the front panel to navigate in the menus and set the parameters
 6 digital controls (encoders) on the front panel, for input management (one per input)
 4 digital controls (encoders) on the front panel, for output management (one per output)
 10 LED indicators on the front panel (one per input and output)
 4 REMOTE ports (0-10VDC) to control the volume of inputs or outputs, select sources, recall
presets etc. from external devices, such as WPm series panels
 PAGER port to connect the MPAGE4 4-zone paging station
 MUTE port for the muting of one or several output zones via external contact closure
 RS-232 interface and compatibility with EclerCOMM software (free download from
http://www.ecler.com/en/products/software.html
) and CA-NET protocol for external remote
control
 Processing:
o Independent level controls for each input and output
o Independent mixing of a combination of inputs (crossing point activation and level) for
each output zone (up to 4 independent mixes of the 6 audio inputs)
o Independent 3-band tone adjustment (BASS-MID-TREBLE) for each input
o Independent crossover filters for each output
o Independent 10-band graphic equalizer for each output
o High-Pass filter with adjustable frequency for the MIC/LINE inputs (inputs 3, 4, 5 and 6)
o Independently configurable PAGER/DUCKER function for the inputs 3, 4, 5 and 6, with 2
priority levels (voice messages or pre-recorded messages with priority, paging from a
paging station, etc.)
o Noise gate, independently configurable for inputs 3, 4, 5 and 6
o Audio feedback (Larsen effect) suppressor, independently configurable for inputs 3, 4, 5
and 6
o Independent delay setting for each output
o Independent compressor/limiter for each output
