Ecler HAK380 - TECHNICAL CHARACTERISTICS

53-0078-0100 M03-05 HAK380.doc 1 of 1
Inputs Sensitivity nom/Impedance PHONO -45 dBV/50kΩ
LINE -10 dBV/50kΩ
SESSION 0 dBV/20kΩ
MICRO (BAL) -50÷-30dBV/1.5kΩ
INSERT (MIC) 0 dBV/100kΩ
EFFECT RETURN 0 dBV/20kΩ
Outputs Level/Minimum Load OUT 1 (BAL) 0(+6)dBV 600Ω 1 (2)V
OUT 1 (UNBAL) 0(+6)dBV 1kΩ 1 (2)V
OUT 2 0(+6)*dBV 1kΩ 1 (2)V
INSERT (MIC) 0dBV/1kΩ
EFFECT SEND 0dBV/1kΩ
REC 0dBV/10kΩ
HEADPHONES 230mW/400Ω
Maximum Input level (full gain) PHONO -26dBV
LINE +9dBV
MICRO -30dBV
Input tone adjust MICRO ±10dB @ 100Hz
±10dB @ 10kHz
Frequency Response PHONO RIAA±0.5dB
LINE 10Hz÷40kHz -1dB
MICRO 10Hz÷30kHz -1dB
THD+N PHONO <0,05%
LINE <0,04%
MICRO <0,05%
RETURN <0,05%
SESSION <0,02%
CMRR MICRO >75dB 1kHz
Signal Noise Ratio PHONO >90dB
LINE >100dB
MICRO >75dB
RETURN >100dB
SESSION >100dB
Tone control BASS -30/+10dB
MID -25/+10dB
TREBLE -30/+10dB
Kill Filters LOW 200Hz
(cut frequency at -6dB) HIGH 6.5kHz
Slope 12dB/oct in all the cases MID 200Hz & 6.5kHz
Phantom voltage +18VDC/5mA max.
Mains 90-264 VAC 47-63 Hz
Power consumption 38VA
Dimensions 265x360x80mm
Weight 4kg
*Internally selectable
