PARTS LIST: PRINTED CIRCUIT 11.1012.03.00
Code
Description
Reference
FCIC55321000
NE5532D
IC113
FCIC55321000
NE5532D
IC114
FCIC07401000
TL074
IC115
FCIC07401000
TL074
IC116
FCIC21641000
SSM2164S
IC117
FCIC07201000
TL072
IC118
FCIC07201000
TL072
IC119
FCIC4580E000
NJM4580E
IC120
FCIC07201000
TL072
IC121
FCIC07201000
TL072
IC122
FCIC07201000
TL072
IC123
FCIC55321000
NE5532D
IC124
FCIC55321000
NE5532D
IC125
FCIC07201000
TL072
IC126
FCIC07201000
TL072
IC127
FCIC07201000
TL072
IC130
FCIC4580E000
NJM4580E
IC131
FCIC07201000
TL072
IC132
FCIC07201000
TL072
IC133
FCIC4580E000
NJM4580E
IC137
FCIC07401000
TL074
IC138
FCIC07201000
TL072
IC139
FCIC25941000
LM2594
IC140
FCIC68200000
BA6820F
IC141
FCIC68200000
BA6820F
IC142
FCBASR060000
YKB21-3035
J101
FRBASR060100
YKB21-3035
J102
FCBASR060000
YKB21-3035
J103
FCBASR060000
YKB21-3035
J104
FRBASR060100
YKB21-3035
J105
FCBASR060000
YKB21-3035
J106
FCCTM0008000
B8B-EH-A
J107
FCCTM0008000
B8B-EH-A
J108
FCCTM0005000
B5B-EH-A
J109
FCTERM050000
Bent Jumper Pin
J110
FCTERM050000
Bent Jumper Pin
J111
FCTERM050000
Bent Jumper Pin
J112
FCTERM050000
Bent Jumper Pin
J113
FCCTM0008000
B8B-EH-A
J114
FCBASR060000
YKB21-3035
J116
FCCTM0003000
B3B-EH-A
J117
FCTERM050000
Bent Jumper Pin
J118
FCTERM050000
Bent Jumper Pin
J119
FCTERM050000
Bent Jumper Pin
J120
FCTERM050000
Bent Jumper Pin
J121
FCBASX100000
YKF52-5003
J122
FCBASX100000
YKF52-5003
J123
FCBASR060000
YKB21-3035
J124
FCCTM0003000
B3B-EH-A
J125
FCBASJ020000
YKB21-5009
J126
FCBASR060000
YKB21-3035
J127
FCBASJ020000
YKB21-5009
J128
FCCTM1003000
S3B-EH
J129
FCCTM0004000
B4B-EH-A
J130
FCCTM0003000
B3B-EH-A
J131
FCCTM1003000
S3B-EH
J132
40-0140-0101 M09-04 NUO2.xls 7 of 16
