Ecler NUO2 - Page 15

PARTS LIST: PRINTED CIRCUIT 11.1012.03.00
Code
Description
Reference
FCCTM1003000
S3B-EH
J133
FCBASR060000
YKB21-3035
J134
FCBASR060000
YKB21-3035
J135
FCCHK0010000
10uH
L101
FCCHK0010000
10uH
L102
FCIND0040000
220uH
L103
FCXTT0857000
BC857B
Q101
FCXTT0857000
BC857B
Q102
FCXTT0857000
BC857B
Q103
FCXTT0857000
BC857B
Q104
FCXTT0857000
BC857B
Q105
FCXTT0857000
BC857B
Q106
FCXR55100000
100k
R101
FCXR55100000
100k
R102
FCXR55100000
100k
R103
FCXR55100000
100k
R104
FCXR55100000
100k
R105
FCXR55100000
100k
R106
FCXR55100000
100k
R107
FCXR55100000
100k
R108
FCXR55100000
100k
R109
FCXR55100000
100k
R110
FCXR54100000
10k0
R111
FCXR54100000
10k0
R112
FCXR54100000
10k0
R113
FCXR54100000
10k0
R114
FCXR55100000
100k
R115
FCXR55100000
100k
R116
FCXR55100000
100k
R117
FCXR55100000
100k
R118
FCXR55100000
100k
R119
FCXR55100000
100k
R120
FCXR55100000
100k
R121
FCXR55100000
100k
R122
FCXR55100000
100k
R123
FCXR55100000
100k
R124
FCXR55100000
100k
R125
FCXR55100000
100k
R126
FCXR55100000
100k
R127
FCXR54215000
21k5
R128
FCXR54215000
21k5
R129
FCXR54215000
21k5
R130
FCXR54215000
21k5
R131
FCXR52100000
100.0
R134
FCXR52100000
100.0
R135
FCXR55100000
100k
R138
FCXR52100000
100.0
R139
FCXR52100000
100.0
R140
FCXR53825000
8k25
R141
FCXR53825000
8k25
R142
FCXR53825000
8k25
R143
FCXR53825000
8k25
R144
FCXR55100000
100k
R147
FCXR55100000
100k
R148
FCXR55100000
100k
R151
FCXR55100000
100k
R152
40-0140-0101 M09-04 NUO2.xls 8 of 16
