WLL
WLL
1000kg
(2200lb)
≥45mm
(≥1.77”)
kg
(lb)
WLL
WLL
1000kg
(2200lb)
≥45mm
(≥1.77”)
kg
(lb)
ULE1000 / ULE2200
1000kg (2200lb)
WLL VS THICKNESS (T)
DATA GRAPH
ULE1000 / ULE2200
1000kg (2200lb)
WLL VS AIRGAP ( )
DATA GRAPH
Note:- Performance
varies with material.
Note:- Performance
varies with material.
