2 Operation and Safety Instructions
2.1 Symbols and Terms Used
SYMBOLS
WLL
1000kg
(2200lb)
≥45mm
(≥1.77”)
The Working Load Limit (formerly Safe Working Load, SWL) (at plate)
The Working Load Limit (formerly Safe Working Load, SWL) (round bar)
✓
==
Correct orientation of load
✕
Do not lift people
✕
Do not lift load over people
✕
✓
Do not lift loads exceeding the recommended length
Air gap warning (See Load Characteristics in Section 4)
TERMS
Poles The two parallel mild steel surfaces on the base of the lifter.
Air-gap Any non-ferrous material that prevents the poles contacting the load.
Paint, rust, scale or even an uneven surface can constitute an air-gap.
WLL
1000kg
(2200lb)
≥45mm
(≥1.77”)
