⑧Speaker output terminals
When connecting the speakers, insert the
ends of the speaker cables so that they do
not touch the speaker body or neighbouring
terminals.
While pressing the terminal with your finger,
insert the speaker cable into the hole. Check
that the speaker cable does not pull out after
the terminal is released.
＊Connect the cable with the black stripe to
the black terminal.
⑨H.P.F. switch
When a sub-woofer is connected to the
amplifier, set this switch to "ON" to cut out
the bass range of the speaker output signal.
