Eclipse CD8061 - Page 103

103
Mounting instruction
CD8061 + 5083 + Power Amplifier (for BALANCE-IN)
NON-FADER(-) L
R
TO BATTERY + 12V (Permanent Supply)
ANTENNA PLUG
MP3 unit
INTERCONNECTING CABLE
TO SIGNAL INPUT OF AUXILIARY POWER AMPLIFIER TO SIGNAL INPUT OF AUXILIARY POWER AMPLIFIER
2
)
2
CD8061
13P
2P
13P
5083
16P
Yellow
Pink
Black
TO GROUND
3
CELLULAR PHONE (For mute)
14
13
FRONT(-)
11
REAR(-)
12
NON-FADER(+)
10
FRONT(+)
9
REAR(+)
L R L R L R L R L R
8
DIGITAL OUT
16
17
12
15
TO POWER ANTENNA RELAY (Supply) TO HEADLIGHT SWITCH (Illumination) TO TURN-ON LEAD OF EACH UNIT (Supply) TO ACC (Power Supply)
Red
Blue
Orange/White
Blue/White
1
4 5 6
