Eclipse CD8061 - Page 104

Mounting instruction
104
CD8061 + 5083 + 5083 + Power Amplifier
ANTENNA PLUG
INTERCONNECTING CABLE
3
)
2P
2P
13P
( A )
( B )
13P
13P
5083 5083
TO GROUND
Red
Blue
Orange/White
Blue/WhitePink
Black
3
17
12
TO POWER ANTENNA RELAY TO HEADLIGHT SWITCH TO TURN-ON LEAD OF EACH UNIT TO ACC (Power Supply)
1
4 5 6
(Supply)
(Illumination)
(Supply)
TO BATTERY + 12V (Permanent Supply)
2
CD8061
13P 16P
Yellow
DIGITAL OUT
TO SIGNAL INPUT OF AUXILIARY POWER AMPLIFIER
MP3 unit
17
CELLULAR PHONE (For mute)
14
NON-FADER(-) L
R
13
FRONT(-)
11
REAR(-)
12
NON-FADER(+)
10
FRONT(+)
9
REAR(+)
L R L R L R L R L R
8
15
Note : 1. The switch on the back side of CD changer ( A ) must be set to the "L" position.
2. The switch on the back side of CD changer ( B ) must be set to the "H" position.
