EKO INSTRUMENTS CO., LTD. 4-20mA Signal Converter MC-11 Instruction Manual V1
Pg. 15
8. Specifications
8-1. Main Unit
Table 8-1. Main Unit Specification
Characteristics
Details
Input Range
DC 0 to 100mV
Output
DC 4 to 20mA
Resolution
<5μV
Input Impedance
>10MΩ
Temperature Response (-20～50℃)
< 0.2%
Accuracy Assured Operating Temperature Range
-20 to +50℃
Operating Humidity Range
< 95RH% (no condensation)
Response Time
1sec. (99% Output)
Non-Linearity
< 0.1% (0-100mV)
Zero Offset
<5μV (Output offset value when 0mV at input @ 500Ω)
Power Supply Voltage Conversion Error
<0.05% (When supply voltage changed from 12V to 24V)
Power Supply
DC 12～24 V ±20%
Power Consumption
0.08～0.75W
Dimension
φ45 × 23mm
Weight
0,24 kg
Aluminium box
IP 65
Dimensions 64 x 98 x 36 / Cable gland M12 (ø3-6mm)
8-2. USB Controller and configurator software
Table 8-2. USB Controller
USB Controller / EKO Sense software
Windows 7, 8
Weight
0,05 kg
Cable
1m / gator clamps
