Ecoflam MINOR 20.1 User Manual

pag.7
LB1007 Minor 20.1/30.1
B
OVERALL DIMENSIONS
H
H
ø 8 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
23
21
19
17
14
9
4
55
50
45
40
34
28
22
H
(m)
ø 8 mm ø 10 mm
0,5
1
1,5
2
2,5
3
3,5
30
35
40
45
50
55
30
65
70
75
80
85
90
95
H
(m)
MAXIMUM LENGTHS OF SUCTION LINES FOR TWO-PIPE SYSTEM (Suntec AS 47 K)
Two-pipe siphon feed system
Two-pipe lift system
Length pipe (m)
Length pipe (m)
H
M8
CC
B
A
G
E
F
D-D1
MODEL AB C DD1E FGHM
MINOR 20.1 318 133 185 175 275 290 106 270 185 M8
MINOR 30.1 318 133 185 175 275 290 130 270 185 M8
D = short head D1 = long head
