pag.32
B
LB752 Minor 4.1/8.1/12.1 - R
TC = SHORT HEAD TL = LONG HEAD
MINOR 4.1 MINOR 4.1 R
N° DESCRIPTION code code
1-OIL PUMP SUNTEC AS 47 K P122 P122
DANFOSS BFP 21 R3 P121/71 P121/71
2-COIL SUNTEC V504 V504
DANFOSS V510/2 V510/2
3-OIL VALVE SUNTEC V410 V410
DANFOSS V412/1 V412/1
4 - COUPLING AEG MP504 MP504
5-NIPPLE BFR01103/001 BFR01103/001
6-HOSES TN 6 x 700 S906 S906
7 - FILTER ART.70451-006PG S105 S105
8 - COVER BFC09052 BFC09052
9 - MOTOR 75 W AEG M181 M181
10 - CAPACITOR 3 µF x 75W C107/9 C107/9
11 - IGNITION TRANSFORMER LANDIS TQ031A27 T136 T136
DANFOSS CM T130 T130
COFI E820 CM T120 T120
12 - CONTROL BOX BASE LANDIS A402 A402
13 - CONTROL BOX LANDIS LOA 24 A117/1 A117/1
14 - PHOTORESISTOR LANDIS A208/3 A208/3
15 - WIRING TERMINAL BOX E228/2 E228/2
16 - PROTECTION BOX BFC09011/1 BFC09011/1
17 - FAN 120 x 60 BFV10053/001 BFV10053/001
18 - AIR CONVEYOR GRMP005 GRMP005
19 - AIR DAMPER - -
20 - COVER AIR INLET GRCA030 GRCA030
21 - CABLES TC BFE01401/1 BFE01401/1
TL BFE01401/2 BFE01401/2
22 - ELECTRODES x COFI BFE01101 BFE01101
x Danfoss/Landis BFE01102 BFE01102
23 - BLAST TUBE TC BFB01253/102 BFB01253/102
TL BFB01253/202 BFB01253/202
24 - FIRING HEAD TC
TL
25 - NOZZLE HOLDER SUPPORT BFC10020/001 BFC10021/001
26 - NOZZLE HOLDER BFC11016 -
Danfoss 030N1218 - PP110
27 - DIFFUSER BFD04006/001 BFD04006/001
28 - ROD TC BFA06108/001 BFA06108/001
TL BFA06106/001 BFA06106/001
29 - GASKET BFG02009/1 BFG02009/1
30 - FLANGE BFF01002 BFF01002
31 - GASKET ø 92 BFG02011 BFG02011
32 - ANTIJAMMING FILTER D.E.M. S132/3 S132/3
33 - PROTECTION BFC03039/5 BFC03039/5
34 - REAR DISC BFD01012/001 BFD01012/001
