Ecoflam MINOR 8.1 User Manual

pag.41
LB752 Minor 4.1/8.1/12.1 - R
C
TC = TETE COURTE TL = TETE LONGUE
MINOR 8.1 cr MINOR 8.1 R cr
N° DESIGNATION code code
1-POMPE COMPLETE SUNTEC AS 47 K P122 P122
DANFOSS BFP 21 R3 P121/71 P121/71
2-BOBINE ELECTROVANNE SUNTEC V504 V504
DANFOSS V510/2 V510/2
3-VANNE SUNTEC V410 V410
DANFOSS V412/1 V412/1
4 - JOINT D'ACCOUPLEMEN AEG MP504 MP504
5-MAMELONS BFR01103/001 BFR01103/001
6-FLEXIBLES TN 6 x 700 S906 S906
7 - FILTRE ART.70451-006PG S105 S105
8- COUVERCLE BFC09052 BFC09052
9 - MOTEUR 100 W AEG M181/2 M181/2
10 - CONDENSATEUR 4 µF x 100 W C107/10 C107/10
11 - TRANSFORMATEUR LANDIS TQ031A27 T136 T136
DANFOSS CM T130 T130
COFI E820 CM T120 T120
12 - SOCLE DE COFFRET LANDIS A402 A402
13 - COFFRET DE SECURITE LANDIS LOA 24 A117/1 A117/1
14 - CELLULE LANDIS A207/2 A207/2
15 - BORNES E228/2 E228/2
16 - COUVERCLE DE BORNES BFC02007 BFC02007
17 - TURBINE 124 x 60 BFV10055/001 BFV10055/001
18 - CONVOYEUR D'AIR GRMP005/1 GRMP005/1
19 - REGLAGE D'AIR SORTIE BFC04011/001 BFC04011/001
20 - VOLET D'AIR BFC04017 BFC04017
21 - CABLE HT TC BFE01401/1 BFE01401/1
TL BFE01401/2 BFE01401/2
22 - ELECTRODE x COFI BFE01101 BFE01101
x Danfoss/Landis BFE01102 BFE01102
23 - GUEULARD TC BFB01211/102 BFB01211/102
TL BFB01211/202 BFB01211/202
24 - TETE DE COMBUSTION TC
TL
25 - SUPPORT PORTE GICLEUR BFC10020/001 BFC10021/001
26 - PORTE GICLEUR BFC11016 -
Danfoss 030N1218 - PP110
27 - DEFLECTEUR BFD04010/001 BFD04010/001
28 - SUPPORT TC BFA06105/001 BFA06105/001
TL BFA06104/001 BFA06104/001
29 - JOINT DE BRULEUR BFG02009/1 BFG02009/1
30 - BRIDE BFF01002 BFF01002
31 - JOINT DE BRULEUR ø 92 BFG02011 BFG02011
32 - FILTRE ANTIPARASITES D.E.M. S132/3 S132/3
33 - SUPPORT CAPOT BFC07101/117 BFC07101/117
34 - CAPOT BFC06101/011 BFC06101/011
