Method 2
You can use the included M6 bolts and nuts to install the charger on a board.
Steps
1. Use the installation board to locate the drilling positions and mark them with a marker.
2. Drill 2 holes of 6 mm diameter.
3. Fix the installation board to the back of the charger with three M5 screws.
4. Insert the M6 bolts through the installation board and into the holes. Then tighten the M6
nuts.
Getting Started
Power On/Off
• Power On: Short press once
• Power Off: Long press for 3s
