EcoFlow EF DELTA User Manual

CONTENTS
1
EF DELTA USE CARE AND SAFETY GUIDE
2
EF DELTA’S FEATURES
LCD DISPLAY
SOLAR PANEL CONNECTION
ENTRY-LEVEL UPS AND SERIES MODE
TECHNICAL SPECIFICATIONS
HOW TO RECHARGE EF DELTA
FAQs
WHAT’S IN THE BOX
OPTIONAL
4
8
9
11
12
12
13
13

EcoFlow EF DELTA Specifications

General

Battery Capacity	1260Wh
AC Charging Input Power	1200W Max
Recharge Time	1.6 hours (AC)
Weight	30.9 lbs (14 kg)
Dimensions	15.7 x 8.3 x 10.6 in (40 x 21 x 27 cm)
Charging Temperature	32 to 113°F (0 to 45°C)
Cycle Life	800 cycles to 80% capacity
Operating Temperature	32 to 113°F (0 to 45°C)
AC Output	1800W (Surge 3300W)
USB-A Output	2 x 5V/2.4A, 12W Max per port
USB-A Fast Charge	2 x 5V, 2.4A / 9V, 2A / 12V, 1.5A (18W Max)
USB-C Output	2 x 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 100W Max per port
Solar Input	400W, 10-65V, 10A
Car Charger Input	12/24V, 8A
Input Voltage	100-120V (US/JP) / 220-240V (EU/UK/AU)
Discharging Temperature	-4 to 113°F (-20 to 45°C)
