EcoFlow POWER HUB - Technical Specifications; Output and Input Specifications

EN
1
Technical Specications
Basic Information
Net Weight 14 kg (31 lbs)
Dimensions (L × W × H) 48 cm × 14 cm × 30 cm (18.9“ x 5.5” x 11.8“)
Wi-Fi Supported (<120 Meters)
Bluetooth (v4.0) Supported (<15 Meters)
Output Spec
Pure sine wave, 3600 W (surge 7200 W, 100 ms),
230 V, 50 Hz (Australian Version: 240 V, 50 Hz)
Linear derating to 1800 W when 40℃ (104°F) < Ambient
Temperature < 60℃ (140°F)
Derating to 3000 W when battery voltage < 49 V
Maximum AC Output
Supported by X-Boost
13.6 V 70 A, maximum power: 1000 W
or 26.4 V 60 A, maximum power: 1600 W
Input Spec
3000 W maximum power, 15 A maximum current,
supported by EcoFlow X-Stream Technology
AC Input Voltage 220–240 V, 50 Hz/60 Hz
PV Input 2/3 15–60 V 30 A, maximum power: 1600 W
Alternator Input
PV Input 1
13–60 V 60 A, maximum power: 1000 W
15–60 V 30 A, maximum power: 1600 W
Battery Port Spec
40-60 V 100 A, supports up to three 2kWh or 5kWh LFP
batteries, which are sold separately.(Not recommended to
use one Power Hub with both a 2kWhLFP and 5kWh battery
at the same time.)
Operating Environment
Operating Temperature –25°C to 60°C (-13°F to 140°F)
Storage Temperature –25°C to 60°C (-13°F to 140°F)
Other
EcoFlow Smart Generator 1800 W maximum charging power, sold separately.
AC Output
DC Output
5200 W
Battery Port (x3)
AC Input Power
