EcoFlow PowerStream - Advanced Solar Panel Wiring; Series or Parallel Wiring

Solar panels in series
Connecting several solar panels in series or in parallel
• If you connect several solar panels in series or in parallel as a group, make
sure that the maximum operating voltage (Vm) and maximum operating
current (Im) of each group do not exceed the maximum input voltage
(55V) and maximum output current (13A) of the microinverter PV input.
• The maximum operating voltage (Vm) and maximum operating current
(Im) of solar panels must to be consistent respectively.
Vm (solar panel 1) + Vm (solar panel 2) < 55V
BKW-Solar
cable
Extension cable Super flat cable
a
X1
b
X4
c
X4
NOTICE
a
b
b
c
c
Solar
panel 1
Solar
panel 3
Solar
panel 2
Solar
panel 4
100W100W
100W100W
100W100W
100W100W
