Specifications
General info
Model
EFWN511/EFWN511B
Dimension
242×169×33 (mm)
Weight
Approximately 3 kg
PV port
Operating voltage
11 - 55 Vd.c.
Maximum input voltage 55 Vd.c.
Maximum input current
13 A
Initial input voltage
15 Vd.c.
Anti-reverse connection protection
Supported
Overvoltage
Ⅱ
Max. PV short circuit current (Isc PV)
14 A
Max. inverter backfeed current to the array
0 A
BAT / DC port
Discharging mode
Maximum input current
13 A
Input voltage
11 -15 Vd.c. , 40 - 59 Vd.c.
Maximum input voltage
59 Vd.c.
Charging mode
Charging voltage
30 - 58 Vd.c.
Maximum charging current
13 A
Rated charging voltage
48 Vd.c.
Overvoltage
Ⅱ
Battery input short circuit current rating
20 A
AC port
Output voltage
220/230/240 Va.c.
25
