EcoFlow PowerStream - Combined Series;Parallel Wiring

Solar panels in both series and parallel
Vm (solar panel 1) + Vm (solar panel 2) < 55V
Im (solar panel 1) + Im (solar panel 2) < 13A
BKW-Solar
cable
Extension cable Super flat cable Solar parallel
connection cable
a
X1
a
b
X4
b
b
c
X4
c
c
d
X2
d
d
Solar
panel 1
Solar
panel 5
Solar
panel 3
Solar
panel 7
Solar
panel 2
Solar
panel 6
Solar
panel 4
Solar
panel 8
100W100W
100W100W
100W100W
100W100W
100W100W
100W100W
100W100W
100W100W
