Technical Specifications
General Specs
Outputs
Input
Net Weight
Dimensions
Capacity
Testing and certification
AC Output (x3) /
(x2 International Version) Full Sine Wave
USB-A Output (x2)
USB-A Fast Charge (x1)
USB-C Output (x1)
Car Power Output (x1)
DC5521 Output (x2)
Solar Charge Input
Car Charger (Example 2)
AC Charge Input Power (Example 1)
AC Charge Input Voltage
100-120Vac (50Hz/60Hz)
International Version 220-240Vac (50Hz/60Hz)
200W 10-25Vdc 12A Max
12Vdc 8A Max
X-Stream Charge 660W Max
600W (Surge 1200W) total, 120Vac (50Hz/60Hz) /
230Vac (50Hz/60Hz)
5Vdc, 2.4A, 12W Max, per port
5Vdc, 9Vdc, 12Vdc, 2.4A, 28W Max
5Vdc, 9Vdc, 12Vdc, 15Vdc 20Vdc, 5A, 100W Max
136W, 13.6Vdc, 10A Max
13.6Vdc, 3A Max (per port)
* 16.8 lbs (7.6kg)
* 11.4 x 7.1 x 9.3 in (28.9 x 18.0 x 23.5 cm)
720Wh (28.8V)
UL Standard, CE, FCC, RoHS, RCM
Battery
Cell Chemistry
Discharge Temperature
Charge Temperature
Shelf Life
Cycle Life
Lithium-ion
-4°F to 140°F (±5°F), -20°C to 60°C (±3°C)
32°F to 113°F (±5°F), 0 to 45°C (±3°C)
1 Year (after fully charged)
800 cycles to 80%+ capacity
* Please Note: The above weight, size, etc. have certain measurement errors. Please refer to the actual
measurement.
