Ecolink Z-Wave TBZ500 User Manual

SETTING THE HEATING OR COOLING TEMPERATURE SETPOINT
Setpoint Change
To change the setpoint, press the Up or Down arrow buttons. The screen will switch to the setpoint change screen (as above)
and show the current setpoint of the current heating or cooling mode. Adjust setpoint temperature up or down with the arrow
buttons.
Note! When in the Setpoint Change screen, pressing the MODE button will switch the setpoint being displayed between
the Heat and Cool setpoints.
Setpoint Push: The cooling setpoint cannot be set below the heating setpoint. The thermostat will “push” the heating setpoint
lower if the cooling setpoint is set below the current heating setpoint. A 3 degree separation is maintained between the heating
and cooling setpoints. The same is true for raising the heating setpoint above the cooling setpoint. The thermostat will “push”
the cooling setpoint up to maintain the 3 degree separation.
Setpoint being
changed
Press MODE button to
change from the heat
setpoint to the cool
setpoint
Press “Done” (FAN button)
to set the setpoint and exit
back to the main thermostat
screen or wait for the screen
to automatically time out.
Copyright © Ecolink Intelligent Technology
TBZ500_manual_8_5x5_5_inch Combined_RDN1240221.indd 21 24-02-2021 18:55
21
Lower Temperature
Pressing the Up or Down buttons
will change the setpoint 1 degree. Press
and hold the button to
ramp the setpoint.
Raise Temperature
Press the Up or Down arrow buttons to
set the desired temperature setpoint
Press either Up or Down
arrow button to go to
the Setpoint Change
screen
