Page 18 ECOM-D
8.4. Soot...Oil trace
The "Soot...Oil trace" menu enables the input of
measured results for boiler temperature, soot dots
and oil trace. Select the desired line on the display
and confirm the input with <Enter>. The input for
boiler temperature and soot measurements 1-3 can
be made one after the other using the instrument
keyboard. Press <Enter> to store the value in the
data record of the measurement.
The result of the oil trace check will be documented as follows:
- Move cursor to "Oil trace"
- Confirm the result with <Enter>
("No", "Yes" or "- - - ")
Once all inputs have been entered, press <ESC> to exit the menu.
The measurement is now complete.
Select :
Boiler temp. : 66°C
1.Soot meas. : -.-
2.Soot meas. : -.-
3.Soot meas. : -.-
Oil trace : ----
Select :
Boiler temp. : 66°C
1.Soot meas. : 1.0
2.Soot meas. : 0.5
3.Soot meas. : 1.5
Oil trace : NO
Make sure to let the probe cool down before
securing it for transport!
