Ecom J2KN - Page 20

“Air free CO measurement”
The J2KN can be used to check CO levels in the gas stream, relative to a 0% O2 concentration. To
view this screen, press the UP or DOWN arrow key in the Gas measurement mode. A screen
similar to the one below will be seen.
The calculated value shown on the line
CO 0% corresponds to the measured
CO concentration if the oxygen
content was 0% in the gas stream.
To store the value, press the
key <Memory> (disk symbol) to store
the result in the intermediate memory.
To printout the values, press <F2>.
Oxygen check
The same type of measurement can be made for only measuring Oxygen. Access this screen by
again pressing the UP or Down key. A screen similar to the one below will be seen.
To store the value, press the
key <Memory> (disk symbol) to store
the result in the intermediate memory.
To printout the values, press <F2>.
O2 17.5
%
CO 0% ppm 738
CO 123
CO measurement 12:15:53
25.11.03
Oxygen Test
O2 19.5
Oxygen check 25.11.03
Stored CO
