Installation
Initial Installation
The AC input source to which the charger is to be connected
must be capable of supplying the current specified on the
charger nameplate.
To properly determine the required AC input service conductor
and branch circuit protection refer to all National and Local
electrical codes. Refer to National Electric Code, ANSI/NFPA 70
sections 310-16, 240-3, 215-3, 210-20, 384-16, 110-14, 210-19,
215-2, 230-42 and table 310-16 for US National Electric Code
conductor sizing and overcurrent protection device
requirements and information. In some applications other
National Electric Code requirements may apply.
Please note that “knockouts” for AC power entry are provided
in the bottom of the unit as shown below. Due to the painted
panel the outline of the knockouts may be hard to see in low
light conditions.
CAUTION: TO REDUCE THE RISK OF FIRE, USE THIS
CHARGER ONLY ON CIRCUITS WITH BRANCH CIRCUIT PROTECTION
(CIRCUIT BREAKER OR FUSE) IN ACCORDANCE WITH THE NATIONAL
ELECTRIC CODE, ANSI/NFPA 70 AND ALL LOCAL CODES AND
ORDINANCES.
