35
Using BIOS
Onboard IDE Controller (Primary)
Use this item to enable or disable the onboard IDE interface.
SATA Mode Selection (IDE)
Use this item to select the mode of the Serial ATA.
USB Controller (Enabled)
This item enables the USB controller. Leave this at the default “Enabled” if you want to
connect USB devices to your computer.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto allows the
system to detect the presence of USB device at startup. If detected, the USB controller
legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled.
OnBoard Audio DEVICE (HDA DEVICE)
Use this item to enable or disable the onboard audio device.
OnBoard SiS191 Lan DEVICE (Enabled)
This item allows you to control the onboard SiS191 Lan device.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network add-in
card with a remote boot ROM installed.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1/2 serial port, and to assign a port
address.
Parallel Port Address (378) (optional)
Use this item to enable or disable the onboard Parallel port, and to assign a port address.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Primary
SATA Mode Selection IDE
USB Controller Enabled
Legacy USB Support Enabled
Onboard Audio DEVICE HDA DEVICE
OnBoard SiS191 Lan DEVICE Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
*Parallel Port Address 378
*Parallel Port Mode ECP
*ECP Mode DMA Channel DMA3
*Parallel Port IRQ IRQ7
DISABLED: disables the
integrated IDE Controller.
PRIMARY: enables only
the Primary IDE Controller.
Help Item
F10: Save and Exit+/-/: Value
Enter : Select
ESC: Exit
F9: Optimized Defaults
F1:General Help
: Move
mnlk
To Next Page
