49
SiS968 SATA RAID Setup Guide
BIOS Utility Operation
BIOS Utility supports windows 2000/XP.
Starting BIOS Utility
1 Boot your system. If this is the first time you have booted with the SiS968 and
the drives installed, the BIOS will display the following:
Silicon Integrated Systems Corp. RAID BIOS Setting Utility 1.00.0.XX
(c) 2006-2008 Silicon Integrated Systems Corp. All Rights Reserved.
Press <Ctrl.<S> to run BIOS Setting Utility
2 Press <Ctrl-S> keys to display the SiS968 Utility Main Menu.
3 You can press <B> key to select the boot disk on the 968 controller. The
yellow highlight will show on the disk and you can switch it to select the disk
you wanted. Press “Enter” key to select it and the selected boot device will be
marked by “*”. The default boot device will be set as Disk 1.
4 Press <R> to display the RAID setup menu below. This is the fastest and
easiest method to creating your first array.
