3
Introducing the Motherboard
This motherboard supports UltraDMA bus mastering with transfer rates of 133/100/66
MB/s.
The motherboard comes with the following expansion options:
Expansion Options
• One PCI Express slot for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One 40-pin IDE connector that support two IDE devices
• One floppy disk drive interface
• Two 7-pin SATA connector
The onboard LAN provides either of the following LAN with following features:
• Integrated Fast Ethernet Controller for PCI Express
TM
Applications
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
Onboard LAN (Optional)
• 10BASE-T/100BASE-TX IEEE 802.3u fast Ethernet transceiver
• Low-power mode
• MII and 7-wire serial interface
• 5.1 Channel High Definition Audio Codec
• ADCs support 44.1k/48k/96k sample rate
• Meets Microsoft WHQL/WLP 3.0x audio requirements
• Direct Sound 3D
TM
compatible
Audio
• 7.1+2 channel High Definition Audio Codec
• All DACs Support 192k/96k/48k/44.1kHz DAC sample rate
• Software selectable 2.5V/3.75V VREFOUT
• Meets Microsoft WHQL/WLP 2.x audio requirements
• Direct Sound 3D
TM
compatible
This motherboard may support either of the following Audio chipsets:
• Integrated Gigabit Ethernet Controller for PCI Express
TM
Applications
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port (optional)
• One VGA port
• Four USB ports
• One 1394a port (optional)
• One LAN port (optional)
• Audio jacks for microphone, line-in and 6/8-channel (optional) line-out
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
