18
Installing the Motherboard
WOL1: Wake On LAN connector (optional)
If you have installed a LAN card, use the cable provided with the card to plug into the
WOL connector onboard. This enables the Wake On LAN (WOL) feature. When
your system is in a power-saving mode, any LAN signal automatically resumes the
system. You must enable this item using the Power Management page of the Setup
Utility in the BIOS. See Chapter 3 for more information.
IRDA: Infrared header
The motherboard supports an Infrared (IRDA) data port. Infrared ports allow the
wireless exchange of information between your computer and similarly equipped
devices such as printers, laptops, Personal Digital Assistants (PDAs), and other
computers.
1 5VSB +5V stand by power
2 GND Ground
3 Ring# Wake up signal (low active)
Pin Signal Name Function
2 Key
1 VCC
3 IRRX
4 GND
5 IRTX
Pin Signal Name
EL: LED headers (optional)
This is an optional header that is used to switch on and off SATA signal light.
2
GND
Pin Signal Name 1 GPIO26
3 EL_GRN_LED
5 EL_YLW_LED
6 KEY
4 GND
Pin Signal Name
Pin Signal Name
Pin Signal Name
