ECS 945GCT-M3 - Advanced BIOS Features

33
Using BIOS
CPU Feature [Press Enter]
Hard Disk Boot Priority [Press Enter]
CPU L1 & L2 Cache [Enabled]
CPU L3 Cache [Enabled]
Hyper-Threading Technology [Enabled]
Quick Power On Self Test [Enabled]
First Boot Device [Floppy]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Boot Other Device [Enabled]
Boot Up Floppy Seek [Disabled]
Boot Up NumLock Status [On]
Gate A20 Option [Fast]
Typematic Rate Setting [Disabled]
Typematic Rate (Chars/Sec0) 6
Typematic Delay (Msec) 250
Security Option [Setup]
HDD Security Freeze Lock [Disabled]
APIC Mode [Enabled]
Advanced BIOS Features
This option defines advanced information about your system.
Item Help

Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Advanced BIOS Features


x
x
123
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
123
CPU Feature (Press Enter)
Users please note that this function is only available for Prescott CPUs. Scroll to
this item and press <Enter> to view the following screen:

Delay Prior to Thermal (16 Min)
Enables you to set the delay time before the CPU enters auto thermal mode.
Thermal Management (Enabled/Thermal Monitor 2) )
This item displays CPU’s temperature and enables you to set a safe temperature to
Prescott CPU.
Phoenix-AwardBIOS CMOS Setup Utility
CPU Feature
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized
Thermal Management [Enabled]
Delay Prior to Thermal [16 Min]
Thermal Management [Thermal Monitor 2]
TM2 Bus Ratio [0 X]
TM2 Bus VID [0.8375V]
Limit CPUID MaxVal [Disabled]
C1E Support [Enabled]
Execute Disable Bit [Disabled]
Vanderpool Technology [Enabled]
Frequency Unlimit [Disabled]
Intel (R) SpeedStep (tm) Tech. [Enabled]
Item Help
Menu Level
Thermal Monitor 1 (On die
throtting)
Thermal Monitor 2 Ratio
& VID transition


F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help

