ECS 945GCT-M3 - Integrated Peripherals

38
Using BIOS
Integrated Peripherals
These options display items that define the operation of peripheral components
on the system’s input/output ports.
OnChip IDE Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
OnChip IDE Device [Press Enter]
Onboard Device [Press Enter]
SuperIO Device [Press Enter]
Item Help

Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals



IDE HDD Block Mode (Enabled)
Block mode is also called block transfer, multiple commands, or multiple sector read/
write. If your IDE hard drive supports block mode (most new drives do), select
Enabled for automatic detection of the optimal number of block read/writes per
sector the drive can support.
ATA 66/100 Cable Msg (Enabled)
This item enables or disables the display of the ATA 66/100 Cable MSG.
IDE HDD Block Mode [Enabled]
ATA 66/100 Cable Msg [Enabled]
IDE DMA transfer access [Enabled]
On-Chip Primary PCI IDE [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
On-Chip Secondary PCI IDE [Enabled]
IDE Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
IDE Secondary Master UDMA [Auto]
IDE Secondary Slave UDMA [Auto]
** On-Chip Serial ATA Setting**
SATA Mode [IDE]
On-Chip Serial ATA [Auto]
SATA PORT Speed Settings [Disabled]
PATA IDE Mode [Primary]
Item Help

Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
OnChip IDE Device

If your IDE hard drive
supports block mode se-
lect Enabled for auto-
matic detection of the
optimal number of block
read/writes per sector the
drive can support
123
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
123
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help



F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
