Installing the Motherboard
SPDIFO: SPDIF out header (optional)
This is an optional header that provides an SPDIFO (Sony/Philips Digital Interface)
output to digital multimedia device through optical fiber or coaxial connector.
S/PDIF: SPDIF out header (optional)
This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface)
output to digital multimedia device through optical fiber or coaxial connector.
JLPC(Low pin count header ) (optional)
9 VCC3 10 FWH1
13 PENABLE 14 NC
15
3VSBY 16 SIRQ
19 LPCPD_L 20 SMBCLK
17 GND 18 GND
11 FWH0 12 GND
1 CK_P_33M_JLPC 2 GND
3
FWH4 4 KEY
5 PCIRST_L1 6 SMBDATA
7 FWH3
8 FWH2
Pin Signal Name Pin Signal Name
1 SPDIFOUT
2 +5V
3 Key
4 GND
Pin Signal Name
1 +5V
2 Key
3 SPDFOUT
4 GND
Pin Signal Name
