54
CrossFire
®
Technology [AMD Dual Graphics] Support
3. Set the CrossFire in Advanced Menu to Enabled. Then press F4 to save the
configuration and exit the BIOS.
4. Click with your right mouse button on My Computer, then click the option
Manage and choose the Device Manager, finally, click the Display Adapters. The
following screen appears. Be sure that the External ATI graphics (ATI Radeon HD
6670) and Onboard graphics (Radeon HD 6530D or HD6550D) are both displaying
in the Display adapters.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.
North Chipset Configuration
IGD Memory [Auto ]
Initate Graphic Adapter [IGD]
CrossFire [Enabled]
CrossFire: Output is IGD Video
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
:Select Item
