55
CrossFire
®
T
echnology [
AMD Dual Graphics]
Suppor
t
5. Enter
AMD VISION Engine Control Center
, you can see the option of
CrossFir
e
TM
,
click it and select
Enable CrossFire
TM
,
then CrossFire
®
starts.
T
o disable
CrossFir
e
®
, please make sure to cancel Enable Cr
ossFir
e
TM
in
Catalyst Control Center firstly
.
Please r
eference latest
AMD Dual Graphics? T
echnology Graphic Car
d
support list on AMD official website and subject to change without no-
tice.
