A68F2P-M4 USER MANUAL
1
Brief Introduction
CPU
Specifications
• FCH A68 (Bolton) Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 32 GB
•
Memory
• 1 x PCI Express x16 Gen3* slot
• 1 x PCI Express x1 slot
• Supported by FCH A68 (Bolton) Chipset
- 4 x Serial ATA 6Gb/s connectors
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-sub (VGA) port
• 1 x HDMI port
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone and Line out)
Rear Panel I/O
• Socket FM2+ for AMD A series processors
• Supports CPU up to 100W TDP
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 1 x USB 3.0 header supports additional two USB 2.0 ports
• 4 x Serial ATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Clear CMOS jumper
• 2 x Front panel USB power select jumpers
• 1 x Rear USB/PS2 power select jumper
• 1 x Debug Card header (LDC)
• 1 x SPDIF out header
Internal I/O
Connectors &
Headers
• Realtek ALC662 6-Ch High Definition audio CODEC
- Compliant with HD audio specification
Audio
LAN
• Realtek RTL8111G Gigabit LAN
Supports DDR3 2133(FM2+)*/1866(FM2)* MHz DDR3 SDRAM
Note: *Due to the limitation of chipset spec, it supports up to
2133/
1866 MHz, 1.5V memory with a single DIMM per channel.
Please go to ECS website for the latest Memory support list.
Note: *FM2+ supports PCI Express Gen3, FM2 supports PCI Express
Gen2.
