ECS A68F2P-M4 User Manual

4
A68F2P-M4 USER MANUAL
F_AUDIO
1
1
COM
MIC_L
MIC_R
LINE_R
AUD_GND
AUD_GND
PRESENCE#
MIC_JD
LINE_JD
1
F_PANEL
Hard disk LED (-)
Hard disk LED (+)
Reset Switch (-)
Reset Switch (+)
NC
Power Switch (-)
Power Switch (+)
MSG LED (+)
MSG LED (-)
Serial Output
Data Carrier Detect
Serial Input
Ring Indicator
Data Terminal ReadyClear to Send
Request to Send
Data Set Ready
Ground
LINE_L
1
9
F_USB1~2
Ground
Ground
Power +5V
Power +5V
GroundUSB Port A (-)
USB Port B (-)
USB Port A (+)
USB Port B (+)
USB3F
1
SSTX1-
USB POWER
SSRX1-
SSRX1+
Ground
SSTX1+
Ground
D1-
D1+
USB POWER
SSRX0-
SSRX0+
Ground
SSTX0+
Ground
D0-
D0+
NC
SSTX0-

ECS A68F2P-M4 Specifications

General

Brand	ECS
Model	A68F2P-M4
Category	Motherboard
Language	English
