A68F2P-M4 USER MANUAL
5
1
LDC
Clock
+3.3V
LAD2 LAD0
Lframe#
LAD1
LAD3 Ground
Reset
SPDIFO
1
SPDIF OUT Ground
VCC
SPK
1
VCC Signal
NC
1
IntruderGround
CASE
USBPWR_F1~2 (Front Panel USB Power Select Jumpers)
VCC
(Default)
5VSB
231 231
CLR_CMOS Jumper
1-2: NORMAL
Before clearing the CMOS, make sure to turn off the system.
CLR_CMOS
2
3
1
2-3: CLEAR CMOS
USBPWR_R (Rear USB PS/2 Power Select Jumper)
2
3
1
2
3
1
VCC
(Default)
5VSB
SYS_FAN
CPU_FAN
Sensor
PWM
Ground
+12V
1
+12V
1
Ground
NC

ECS A68F2P-M4 Specifications

General

Brand	ECS
Model	A68F2P-M4
Category	Motherboard
Language	English
