Page #44 background imageLoading...
Page #44 background image
40
Using BIOS
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
CAS Latency (Tcl) (8 CLK, N/A)
Memory CLK (533 MHz, N/A)
This item is used to set the memory clock mode.
RAS/CAS Delay (Trcd) (8 CLK, N/A)
This item specifies the Row precharge to Active or Auto-Refresh of the same bank.
Row Precharge Time (Trp) (8 CLK, N/A)
This item controls the timing delay (inclockcycles) before the DRAM starts a read
command after receiving it.
This is the amount of time a CAS is performed after a RAS. The lower the better, but
some DRAM does not support low figures.
This item determins the time RAS takes to read from and write to a memory cell.
Min Active RAS (Tras) (20 CLK, N/A)
Row Cycle (Trc) (27 CLK, N/A)
Use this item to specify the Row Cycle Time.
RAS/RAS Delay (Trrd) (4 CLK, N/A)
This item specifies the active-to-active delay of different banks.
Bank Interleaving (Auto)
This item is used to set the bank interleaving.
DRAM Timing Mode (Auto)
This item enables you to specify the DRAM timing mode to be configured automati-
cally or manually.
Channel Interleaving (XOR of Address bits)
This item is used to set the channel interleaving.
Press <Esc> to return to the M.I.B.II page.
Advanced Clock Calibration (Auto)
This item can enable greater performance tuning margin for the AMD Phenom
TM
Black Edition CPUs. The optimal gain can be seen in configurations that use high-
end CPU cooling solution in combination with elevated CPU core voltage (CPU
VID) value. The motherboards that support “advanced Clock Calibration”-feature
should enable power delivery capabilities, specifications in order to maximize the
performance tuning potential.
Special ACC (Disabled)
Select disable or enable, Special ACC for ACC “Advanced Clock Calibration” func-
tion.
Warning:User please notice, when enable “Special ACC”
item, it may cause unexpected issue.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS A785GM-AD3 and is the answer not in the manual?

ECS A785GM-AD3 Specifications

General IconGeneral
Number of memory slots4
Maximum internal memory8 GB
Processor socketSocket AM3
Processor manufacturerAMD
USB 2.0 connectors8
Power fan connectorYes
Number of SATA connectors5
PS/2 ports quantity2
USB 2.0 ports quantity6
Ethernet LAN (RJ-45) ports1
Firewire (IEEE 1394) ports-
Audio chipRealtek ALC888S
CertificationROHS, EuP
Motherboard chipsetAMD 785G
Audio output channels7.1 channels
Motherboard form factorATX
Compatible operating systemsWindows Vista, 7
PCI slots3
Maximum graphics card memory512 MB
RAID levels0, 1
LAN controllerRealtek RTL8111DL
Networking featuresGigabit Ethernet
BIOS typeAMI
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width305 mm
