Using BIOS
M.I.B. (MB Intelligent Bios)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
M.I.B. (MB Intelligent Bios)
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized DefaultsF1:General Help
: Move
CPU Frequency Ctrl: Disabled
Memory Configuration Press Enter
Advanced Clock Calibration Disabled
Auto Detect DIMM/PCI CIK Enabled
CPU/HT Reference Clock (MHz) 200
Spread Spectrum Disabled
HT Frequency Auto
Voltage Function Disabled
AMD Phenom (tm) II X3 720 Processor
Speed : 2800MHz, NB Clk: 2000MHz
Tells BIOS whether to
use the setup options
below this to
configure the
P-Status, or whether
to configure the
P-Status automatically
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
Memory Configuration
Scroll to this item and press <Enter> to view the following screen:
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Memory Configuration
Memory Configuration
DRAM Frequency Auto
DRAM Timing Mode Auto
Bank Interleaving Auto
Channel Interleaving XOR of Address bits
Help Item
Options
Auto
Limit
Manual
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized DefaultsF1:General Help
: Move
Memory CLK : 400 MHz, N/A
CAS Latency (Tcl) : 6 CLK, N/A
RAS/CAS Delay (Trcd) : 6 CLK, N/A
Row Precharge Time (Trp) : 6 CLK, N/A
Min Active RAS (Tras) : 15 CLK, N/A
RAS/RAS Delay (Trrd) : 4 CLK, N/A
Row Cycle (Trc) : 20 CLK, N/A
CPU Frequency Ctrl (Disabled)
Use this item to enable or disable CPU frequency controller.
To Next Page
