5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
* stands for optional components
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
processor (socket AM2+)/AMD
Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/Sempron
TM
processors
2. DIMM1~2 240-pin DDR2 SDRAM slots
3. FDD Floppy disk drive connector
4. PWR1 Standard 24-Pin ATX Power connector
5. IDE1 Primary IDE connector
6. SPK1 Speaker header
7. SATA1~4 Serial ATA connectors
8. IR1* Infrared header
9. CLR_CMOS Clear CMOS jumper
10. PANEL1 Front Panel Switch/LED header
11. USBPWR_F Front Panel USB Power Select jumper
12. F_USB1~3 Front Panel USB headers
13. SYS_FAN System cooling fan connector
14. SPDIFO1 SPDIF out header
15. CD_IN Analog Audio Input header
16. F_AUDIO Front Panel Audio header
17. PCI1~2 32-bit add-on card slots
18. PCIEX1 PCI Express x1 slot
19. PCIEX16 PCI Express x16 graphics card slot
20. USBPWR_R Rear USB/PS2 Power Select jumper
21. PWR2 4-pin +12V power connector
22. CPU_FAN CPU cooling fan connector
