GLKD-I2 USER MANUAL
1
Brief Introduction
Specifications
SoC
• Single channel DDR4 SO-DIMM memory architecture
• 1 x 228-pin DDR4 SO-DIMM socket supports up to 8 GB
• Supports DDR4 2400 MHz SDRAM
Memory
• 1 x M.2 slot (Socket 3 key A/E 2230 for WiFi/BT supports
CNVi)
• Supported by Intel
®
Gemini Lake 1090 BGA 14nm
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit LAN
• Realtek ALC662-VD0-GR 6CH HD Audio CODEC
- 6-Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
• Onboard Intel
®
Gemini Lake 1090 BGA 14nm
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x Serial ATA 6Gb/s connectors
• 2 x COM headers
• 1 x Buzzer
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x Case open header
• 1 x Printer header
Internal I/O
Connectors &
Headers
Note: Please go to our website for the latest Memory support list.
• 1 x PS/2 Keyboard & PS/2 Mouse connectors
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x HDMI port
• 1 x D-sub (VGA) port*(or DP port)
• 1 x Audio port (1 x line-in, 1 x line-out, 1 x Microphone)
Note: * VGA port (rear panel I/O) and DP port (rear panel I/O) are alternative
options of the motherboard.
