GLKD-I2 USER MANUAL

Table of Motherboard Components

LABEL COMPONENTS

1. SoC

Onboard Intel

Gemini Lake 1090 BGA 14nm

2. CASE Case open header

3. DIMM 228-pin DDR4 SDRAM SO-DIMM

4. BZ Buzzer

5. SYS_FAN 4-pin system cooling fan connector

6. F_PANEL Front panel switch/LED header

7. LPT Onboard parallel port header

8. COM1~2 Onboard serial port headers

9. SATA1~2 Serial ATA 6Gb/s connectors

10. M2_2230

M.2 slot for 2230 WiFi/BT (supports intel

build-in WiFi/BT)

11. F_AUDIO Front panel audio header

12. F_USB1~2 Front panel USB 2.0 headers

13. BAT Battery

14. CLR_CMOS Clear CMOS jumper

15. ATX_POWER Standard 24-pin ATX power connector

Note: * VGA port(rear panel I/O) and DP port (rear panel I/O) are alternative

options of the motherboard.
