ECS H55H-CM

42
Using BIOS
Delta (+3)
This item specifies the range that controls CPU temperature and keeps it fromgoing
so high or so low when smart fan works.
SMART Fan Slope PWM value (4)
This item is used to set the Slope Select PWM of the smart fan.
CPU Fan Full Speed Offset (-) (7)
This item is used to set the CPU fan full speed offset value.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• System Temperature
• CPU Fan Speed
• CPU Vcore
• VDIMM
Press <Esc> to return to the main menu setting page.
Press <Esc> to return to the PC Health Status page.
Case Open Warning (Disabled)
This item enables or disables the warning if the case is opened up, and the item below
indicates the current status of the case.
Chassis Opened (No)
This item indicates whether the case has been opened.
