ECS H55H-CM User Manual

41
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU SMART FAN Control Enabled
SMART Fan Mode Silent
CPU SMART Fan start PWM 5
SMART Fan start PWM TEMP (-) 26
DeltaT +3
SMART Fan Slope PWM value 6
CPU Fan Full Speed Offset (-) 6
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Options

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CPU SMART FAN Control Enabled
SMART Fan Mode Manual
CPU SMART Fan start PWM 5
SMART Fan start PWM TEMP (-) 26
DeltaT +3
SMART Fan Slope PWM value 6
CPU Fan Full Speed Offset (-) 6
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CPU SMART Fan start PWM (28)
This item is used to set the start PWM value of the CPU smart fan.
SMART Fan start PWM TEMP (-) (32)
This item is used to set the start temperature of the smart fan.
Press <Esc> to return to the Smart Fan Function page.
