ECS H55H-M User Manual

6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1156 socket for Intel
®
Core
T
M
i7-800/Core
T
M
i5/
Core
T
M
i3 and Pentium
®
p
rocessor series
2. DDR3_1~2 240-pin DDR3 SDRAM slots
3. ATX_POWER Standard 24-pin ATX power connector
4. SPI_DEBUG SPI debug header
5. SATA1~6 Serial ATA connectors
6. F_PANEL Front panel switch/LED header
7. CLR_CMOS Clear CMOS jumper
8. CASE Chassis detect header
9. F_USB1~2 Front panel USB headers
10.ME_UNLOCK ME unlock header
11. SPDIFO SPDIF out header
12. F_AUDIO Front panel audio header
13. PCI 32-bit add-on card slot
14. PCIE1~2 PCI Express x1 slots
15. PCIE16X PCI Express x16 graphics card slot
16. SYS_FAN System cooling fan connector
17. CPU_FAN CPU cooling fan connector
18. ATX12V4P 4-pin +12V power connector
1. CPU Socket

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
