Introducing the Motherboard

Feature

The motherboard uses an LGA1156 type of Intel

Core

i7-800/Core

i5/

Core

i3 and Pentium

processor series that carries the following features:

Processor

• Intel

Core

i7-800/Core

i5/Core

i3 and Pentium

processor series

• Supports “Hyper-Threading” technology CPU

“Hyper-Threading” technology enables the operating system into thinking it’s

hooked up to two processors, allowing two threads to be run in parallel, both on

separate “logical” processors within the same physical processor.

Memory

• Supports DDR3 1333/1066 DDR3 SDRAM with Dual-channel architec-

ture

• Accommodates two unbuffered DIMMs

• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB

This board supports CPU up to 95W TDP.

• One x16 PCI Express Gen2 ports each supporting up to 8 GB/s direc-

tion peak bandwidth

• Compliant with PCI Rev 2.3 interface at 33 MHz

• Integrated SATA 3.0 Gb/s Host Controller

• Ten USB 2.0 ports supported

• Serial Peripheral Interface (SPI) support

• Enhanced DMA Controller, interrupt controller, and timer functions

• Integrated Graphics Support with PAVP 1.5

The Intel H55 Express Chipset is a single-chip with proven reliability and per-

formance.

Chipset

Onboard LAN (optional)

• PCI Express base 1.1 compliant

• Compliant with IEEE 802.3u specification for 10/100 Mbps Ethernet

• IEEE 802.3x compliant flow control support

• IEEE 802.3ab Auto-Negotiation support

• PCI Express base 1.1 compliant

• Compliant with IEEE 802.3u/IEEE 802.3ab specification for 1000Mbps

Ethernet

• IEEE 802.3x compliant flow control support

• IEEE 802.3ab Auto-Negotiation support

Questions and Answers:

Need help?

Do you have a question about the ECS H55H-M and is the answer not in the manual?

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit
