ECS H55H-M User Manual

13
Installing the Motherboard
Table A: DDR3 (memory module) QVL (Qualified Vendor List)
The following DDR3 1333/1066 memory modules have been tested and qualified for
use with this motherboard.
Type Size Vendor Module Name
512 MB ELPIDA PC3-8500U-7-00-AP
Hynix HYMT112U64ZNF8-G8 AA
Hynix HMT112U6AFP8C-G7N0 AA
Kingston KVR1066D3N7/1G
Micron MT8JTF12864AY-1G1D1
Micron MT8JTF12864AY-1G1D1
Ramaxel RMR1810NA48E7F-1066-LF
Samsung GOLD BAR M378B2873DZ1-CF8 0818
Hynix HYMT125U64ZNF8-G8 AA
Hynix HMT125U6AFP8C-G7N0 AA
Micron MT16JTF25664AY-1G1D1
Micron MT16JTF25664AY-1G1D1
Samsung M378B5673DZ1-CF8 0842
A-DATA AD3U1333B1G9-B
Hynix HMT112U6AFP8C-H9N0 A A
Kingston KVR1333D3N9/1G
Micron MT8JTF12864AY-1G4D1
Micron MT8JTF12864AZ-1G4F1
Samsung M378B2873DZ1-CH9
Samsung M378B2873EH1-CH9
Silicon Pow er SP001GBLTU133S01
PSC A L 7F8 G73 D- DG1
A-DATA AD3U1333B2G9-B
Apacer 78.A1GC6.9L1
elixir M2F2G64CB8HA4N-CG 0903.TW
Hynix HMT125U6AFP8C-H9N0 A A
Kingston KVR1333D3N9/2G
Micron MT16JTF25664AY-1G4D1
PSC A L 8F8 G73 D- DG1
Ramaxel RMR186EA48D8F-1333
Samsung M378B5673EH1-CH9
Silicon Pow er SP002GBLTU133S01
1 GB
2 GB
DDR3 1066
1 GB
DDR3 1333
2 GB

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
