ECS H55H-M User Manual

Setting Up eJIFFY
58
1. Select the image you want to save and press the right key of your mouse to show
the menu, then click the option “ Save Image As” from the menu.
Q2: How to save image file through eWeb?
3. eWeb supports to open video/audio files online in Flash player format.
Due to firefox limitation, the browser does not support files in Real player
or Media player formats.
2. eWeb does not support Office Viewer/Reader/Writer format under eJIFFY
interface. Please enter the Operating System to open Office files.
Note:
1. Before downloading files, please “mount” the storage devices to make
sure the device is connected with eJIFFY interface. (Please refer to the
usage FAQ to mount devices)
Q1: How to download files to hard disk through eWeb?
Click on the file link directly. Then select “Save File” in the pop-up window.
eWeb: Firefox for web browsing/webmail and watching flash video.

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
