43
Using BIOS
Voltage Function (Disabled)
Use this item to enable or disable the Voltage Function. If enable, users can increasethe
hardware voltage through BIOS settings.
Intel (R) Core (TM) i5 CPU 661 @ 3.33GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Ratio Status/Ratio Actual Value (Unlocked/25)
These items show the locked/unlocked ratio status and the actual ratio of the CPU
installed in your system.
Current Memory Frequency (1333MHz)
This item displays the current memory frequency.
CPU Vcore (1.164 V)
This item displays the current CPU voltage.
Memory Current Type (9-24-9-9-10-74-5-4-5-20)
This item displays the current memory type.
CPU VTT Voltage (1.104 V)
This item displays the current CPU VTT voltage.
VDIMM (1.524 V)
This item displays the current DIMM voltage.
PCH Voltage (1.044 V)
This item displays the current PCH voltage.
Press <Esc> to return to the main menu setting page.
PCIE Over-clocking Func (Disabled)
This item enables or disables the PCIE over-clocking function.
Spread Spectrum (Enabled)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
