Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the H55H-M2 motherboard. This motherboard is a high

performance, enhanced function motherboard designed to support the LGA1156

socket for latest Intel

Core

i7/Core

i5/Core

i3 processors for high-end busi-

ness or personal desktop markets.

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one PS/2 mouse and keyboard combo connector, one DVI port, one VGA

port, six USB ports, one ESATA port, two LAN ports, one SPDIF output port and

audio jacks for microphone, line-in and 8-ch line-out.

This motherboard is based on Intel

H55 Express Chipset for best desktop platform

solution. H55 is a single-chip, highly integrated, high performance Hyper-Threading

peripheral controller, unmatched by any other single chip-device controller. This

motherboard supports up to 16 GB of system memory with dual channel DDR3

1333/1066 MHz. Two PCI slots are supported, fully compliant with PCI rev 2.3

specification at 33MHz. High resolution graphics via one PCI Express slot, intended

for Graphics Interface, is fully compliant to the PCI Express Base Specification

revision 2.0. Additionally, one PCI Express x4 slot is supported, fully compliant to

the PCI Express Base Specificaiton revision 2.0 as well. It implements an EHCI

compliant interface that provides twelve USB 2.0 ports (six USB ports and three

USB 2.0 headers support additional six USB ports).

ECS H55H-M2 User Manual
